CNFJ

CNFJ Series (Energy Storage AGM Gel Battery)
Features
(1) Capacity Range (C120): 200Ah-3000Ah (25 ℃);
(2) Long cycle life: 20% DOD cycle times of 2V Series is more than 2200 (Under 25 ℃);
(3) Self-discharge: ≤1% / month (25 ℃);
(4) Efficiency of sealed reaction: ≥99%;
(5) Compact structure, anti-vibration performance and high energy density;
(6) Good performance in high and low temperature
(7) Operating temperature range: -20 ~ 50 ℃.

Product details

Scope
Solar photovoltaic energy storage system
Energy storage system of wind power

Model	Nominal Voltage	Capacity	Dimension				±3%(kg) Weight ±3%	Terminal
Model	Nominal Voltage	Capacity	Length	Width	Height	Total Height	±3%(kg) Weight ±3%	Model	Position
CNFJ17-12A	12	17	181	76.5	167	167	5.25	引线	D
CNFJ17-12G							4.95
CNFJ17-12D							5.55
CNFJ18-12	12	18	181	77	168	168	5.1	引线	D
CNFJ18-12H			181	77	171	171	5.6
CNFJ18-12E			181	76.5	167	167	5.35
CNFJ20-12	12	20	181	76.5	169	169	5.6	引线	D
CNFJ22-12A	12	22	181	76.5	167	167	5.9	引线	D
CNFJ24-12	12	24	166	175.5	127	127	8	引线	D
CNFJ26-12	12	28	165	125	175	182	7.3	引线	D
CNFJ28-12E			165	125	175	175	9		D
CNFJ28-12B			164.5	175	127	127	8		B
CNFJ55-14	14	55	260	169	213	217	20	引线	\
CNFJ200-6	6	200	307	169	222	225	27.5	引线	F
CNFJ200-6A			260	180	248	264	27.8		F
CNFJ200-6C			323	178	224	228	26.8		E
CNFJ225-6	6	225	260	180	248	251	29.5	引线	F
CNFJ32-12	12	35	198	131	155	177	9.2	引线	C
CNFJ35-12B	12	35	198	131	158	158	10	引线	C
CNFJ36-12	12	36	198	131	155	177	10.5	引线	C
CNFJ36-12B	12	36	198	131	158	158	10.5	引线	C
CNFJ38-12A	12	38	196	165	175	182	12	引线	D
CNFJ38-12C	12	38	197	166	169	169	12	引线	D
CNFJ40-12A	12	40	196	165	175	182	12.6	引线	D
CNFJ50-12G	12	50	197	166	169	169	13.5	引线	D
CNFJ50-12A			196	165	175	182	13.5		D
CNFJ50-12C			229	136	210	232	16		C
CNFJ55-12D	12	55	229	136	210	232	16.8	引线	D
CNFJ60-12	12	60	261	167	184	188	20	引线	D
CNFJ65-12	12	65	351	166	173	184	20	引线	C
CNFJ65-12F	12	65	351	166	173	178	20.5	引线	C
CNFJ70-12	12	70	259	168	210	232	22.0	引线	C
CNFJ75-12	12	75	259	168	210	232	23	引线	C
CNFJ80-12A	12	80	351	166	176	176	22.8	引线	D
CNFJ80-12H			306	169	208	232	26		C
CNFJ80-12D			332	175	215	243	24.3		C
CNFJ90-12	12	90	306	169	208	232	26	引线	C
CNFJ90-12C	12	90	332	175	215	223	28	引线	C
CNFJ100-12	12	100	332	175	215	243	29	引线	C
CNFJ100-12M			408	174	207	240	30.5
CNFJ100-12D			332	175	221	243	30.5
CNFJ110-12	12	110	332	175	215	243	29	引线	C
CNFJ120-12	12	120	408	174	207	240	34	引线	C
CNFJ134-12	12	134	341	173	283	285	40	引线	C
CNFJ150-12	12	150	483	170	242	240	41	引线	C
CNFJ180-12	12	180	530	209	214	240	50.5	引线	B
CNFJ200-12	12	200	530	209	214	240	53	引线	B
CNFJ200-12A	12	200	522	240	219	244	56.2	引线	B
CNFJ250-12	12	250	520	268	220	245	68.6	引线	B
CNFJ100-2B	2	100	171	72	206	---	5.55	引线	G
CNFJ120-2	2	120	171	72	206	---	6.4	引线	G
CNFJ150-2	2	150	171	101	206	---	8.2	引线	G
CNFJ150-2A	2	150	171	130	206	239	8.2	引线	G
CNFJ200-2	2	200	171	106	332	365	13	引线	G
CNFJ300-2	2	300	170	150	332	365	18.2	引线	G
CNFJ400-2	2	400	211	176	329	367	26	引线	H
CNFJ500-2	2	500	243	173	330	364	30	引线	H
CNFJ600-2	2	600	304	175	331	366	36.7	引线	H
CNFJ800-2	2	800	410	175	335	365	52.5	引线	I
CNFJ1000-2	2	1000	475	171	331	364	60.5	引线	I
CNFJ1200-2	2	1200	475	171	331	364	65.5	引线	I
CNFJ1500-2	2	1500	401	351	342	378	90.0	引线	I
CNFJ2000-2	2	2000	490	350	345	383	125.0	引线	I
CNFJ3000-2	2	3000	712	353	341	382	190.0	引线	I
